Rack Mount Power Supply 17 Way 12V 20A
Item Code : POW572
Product Details
Antihum Rack Mount Power Supply
antihum - Rack Mount Power Supply 17 Way 12V 20A
Item Code: POW572
Brand: antihum
Manufacturer: antihum
Description
This Power Supply will convert the input of 240V AC to 17 outputs of 12V with a total current output of 20 Amps.
Sixteen (16) of the output ports are fused at 2A each
One of the outputs are fused at 4A.
The power supply is protected for safety by a Automatic Re-setting overload protection circuit.
The power supply comes complete with a UK Mains Lead fitted with IEC 6 Amp Socket and UK Square Pin Mains Plug.
Features
- 12Volt 20 Amp
- Each output has its own individual PTC Self-resetting Fuse
- Can Power upto 16-17 Cameras upto a maximum load of 20 Amps
- LED indicator of Power Supply Status.
Specification
| Mechanical Specification | ||
|---|---|---|
| Mains Input Port: | IEC 6 Amp Plug | |
| Output Ports: | 17 x DC screw terminal | |
| Dimensions of Power Supply Body: | 236 x 300 x 67mm (excludes cable entry requirements) | |
| Electrical Specification | ||
| Input Voltage Range: | 100-240 Volt AC | |
| Output Voltage: | 12 Volts DC | |
| Output Current: | 20 Amp | |
| Output Power: | 240W | |
Short Circuit Protection: | Yes | |
