KEF - In Wall Subwoofer 4 ohm 490x128x81mm - Ci4100QLb

Item Code : Ci4100QLb



Special Notice: This Item is only sold when part of an installed Audio System.

Special Notice: This Item is only sold when part of an installed Audio System.

Product Details

KEF™   Architectural Speaker

KEF - KEF - In Wall Subwoofer 4 ohm 490x128x81mm - Ci4100QLb

Item Code: Ci4100QLb

Brand: KEF

Manufacturer: KEF


Important Notice.

This item is a trade only supplied & Installed Item.

This selected KEF Loudspeaker and its required Amplifier KASA500 is only available for sale when part of an installed Audio Visual System, if it is required for you to purchase this as an individual item then please follow this link DealerLocator , to establish your nearest KEF recommended Retailers.

Description

The Ci4100QLb in-wall subwoofer features four compact 100mm (4in.) LF drivers. Housed in a rigid aluminum frame with a total mounting depth of 76mm (3in.), the Ci4100QLb can be mounted in any standard wall cavity.

Easy to install and stunning to behold (both visually and acoustically), KEF's all-new range of rectangular in-wall speakers are designed and engineered for serious music and home theater systems.

Technical Drawing Ci4100QLb

Technical drawing with dimensions Ci4100QLb

Specification

Colour White
Nominal Impedance 4 Ω
Sensitivity 90dB (2.83V/ 1m)
Frequency Response 35Hz - 120Hz (±6dB) open backed
Drive Units LF: 4 x 100mm (4 in.)
Amplifier requirements KASA500
Product external dimensions H x W x D : 490 x 128 x 81 mm (19.29 x 5.04 x 3.19 in.)
Cut-out dimensions H x W : 476 x 114mm (18.74 x 4.49 in.)
Mounting depth from surface 76mm (3.0 in.)
Net Weight 3 kg (6.61 lbs)
Unit measurement Piece
Document Download Ci4100QLb Information Sheet
Ci Series Pamphlet
Ci Series Specification Sheet
User Manual
Ci Series Minimum Cabinet Volume Chart
Product drawing
EASE GLL Data
Remarks KEF reserves the right, in line with continuing research and development, to amend or change specifications. E&OE.
